8x8C 50M HDMI Matrix Extender

更新:2016-01-05 12:14:39      点击:
  • 品牌:   COAS
  • 型号:   HD808CF
  • 在线订购
产品介绍








     HDMI Matrix extender

Model No .HD808CF

FEATURE

any 8 HDMI input signal split to any 8 outputs for 8-supplied receivers

Support 50m for HDMI signal
The receiver is 8 sets of Cat5e/6 - RX  ( two RJ45 sockets with IR ) HDMI device


Bi-direcional  coas IR control system
Receiver Range : 20 meter
Emitter Range :    6 meter

IR cable can be up to 300 meter



SPECIFICATION

HDMI version                                        4K x 2K

HDCP                                                   1.3

Bandwidth                                            6.75Gbps - 10.2Gbps

Output Resolution                                3840 x 2160@50/60, 480i — 1080P@ 50/60
                                                         1080P@24/50/60 , VGA -UXGA

Operating Temperature                        -15°C~55°C/5°F~131°F

Deep Color                                          deep color 24bit/36bit

Audio Format                                    PLCM /Dolby -AC3/DTS7.1 / DSD

Housing                                                Metal

Output cable distance                        <&= 20m
Intput cable distance                          <&= 20m
Dimension                                          442mm(L)x204mm(W)x47mm(H)

Weight                                                g

Power Supply                                     DC 12V  /4A



OPERATION :
1, Connect the signal source ( such as HD-DVD, PS3 , STB ) with HDMI input interfaces .
2, Connect the display devices ( such as HD-LCD , HD-DLP) with HDMI output interfaces .
3, This device is powered by an external power supply ( included ) .

Package included :
1 x HDMI matrix over UTP
4 x 50m HDMI over 2 x Cat5e/6 extenders RECEIVERS with IR
1 x12V / 10A DC power adapters
4 x 5V/2A DC power adapters
1x remote control
1x user manual
8 x IR TX + 8 x IR RX if needed


Included in the system are an HDMI splitter, eight receivers, eight  IR transmitters & receivers, and eight 5 V DC power supply adapters.

8 x HDMI source devices matrix switched to 8 x Cat5e/6 Extender output devices

 .50M transmission over Cat 6 at 4K x 2K

 .UTP Cat 5e/6 to up to 4 compatible displays

.Compliant with HDMI 1.4, HDCP 1.3

.HDMI local loop out

.Operates for TMDS clock frequencies up to 165 MHz

.Supports resolutions up to 3840 x 2160 /36-bit/48-bit

.Supports LPCM 7.1/AC3, Dolby True HD, and DTS-HD master audio

.Super IR & RS 232 control system , IR transport channel can be forward or backward per your installation

 .Front-panel LEDs for input signal presence

.Front -panel LEDs digital display

.CEC Pass through

External and internal EDID settings

.Bi-directional IR control
